BRONZE RIGGING SCREWS
OPEN / TERMINAL
| Item No | Wire diam (mm) | Thread size | Breaking Load (kg) |
|---|---|---|---|
| 3 | 1/4" | 1550 | |
| 4 | 1/4" | 1550 | |
| 4 | 5/16" | 2450 | |
| 5 | 5/16" | 2450 | |
| 5 | 3/8" | 3450 | |
| 6 | 3/8" | 3450 | |
| 6 | 7/16" | 4750 | |
| 7 | 7/16" | 4750 | |
| 7 | 1/2" | 6200 | |
| 8 | 1/2" | 6200 | |
| 8 | 5/8" | 9500 | |
| 10 | 5/8" | 9500 | |
| 10 | 3/4" | 12500 | |
| 12 | 3/4" | 12500 | |
| 12 | 7/8" | 18000 | |
| 14 | 7/8" | 18000 | |
| 16 | 1" | 00 |
