D-SHACKLES, CAPTIVE PIN
| Item No | SWL (kg) | BRL (kg) | ØPin (mm) | W (mm) | L (mm) | Width (mm) | Height (mm) | ØA (mm) | ØB (mm) |
|---|
| 307-019 | 250 | 1000 | 5 | 10 | 17 | 20 | 30 | | |
| 307-020 | 350 | 1400 | 6 | 12 | 21 | 24 | 36 | | |
| 307-021 | 700 | 2800 | 8 | 16 | 32 | 32 | 51 | | |
| 307-024 | 1000 | 4000 | 10 | 20 | 34 | 40 | 59 | | |
| 307-044 | 2550 | 6200 | 12 | 25 | 39 | 49 | 69 | | |
